Springer Plans - New Design Retains Old School Look!

springer fork plans

Our new springer plans are a brand new design that has an old school look but has a cutting edge feel.

These springer fork plans will be a great addition to your next bike build or current project. Or, build them and sell them for a tidy profit!

Springer front end plans are hard to come by. Good springer plans, that is.

And we have the best plans on the planet, guaranteed.

All of our plans are designed by our Senior Engineer and they are reviewed by a second senior engineer for accuracy.

This set of plans will be printed and delivered 36" x 72" in size.

Springer Front End Plans Features:

  • Tube Diameter is 1.5" DOM Standard Carbon Steel
  • Frame Rake angle = 30 degrees
  • 1.5" Side Tube Design with 1" fork diameter.
  • External Spring Width = 13.5" External
  • Internal Spring Width = 10.0" Internal Dim between tubes and 11.5" between axle plates
  • Distance = 10.5" (200 Series)
  • Material - Standard Mill Carbon Steel
  • Rake = 30 Degrees (Stock Rake)
  • Wheel Diameters = 26" (Both)

Our springer blueprints are only $49.95 $29.95, and they are 36 inches by 72 inches!

We used your plans several years ago to create the springer forks shown in the photos. They worked very well and provided a responsive suspension and straight and true ride on the finished bike. We were pleased with the results.

Michael Smith.

Here's How The Springer Front End Will Look On Our Rigid Sportster Frame:

data-ad-format="horizontal">
sportster springer front end

Here's Rear View Of The Springer Fork Design:

Springer Forks

The advantage you'll have with this set of plans over any other set is that you'll get sectional views. Sectional views make all the bends and cuts easier to see and understand. You'll have an easier time reading the plans, and therefore your forks will be built much faster and with less headaches, if any.

Your final product is sure to turn heads up and down the road!
